3kw 24v Hybrid Inverter IP54

Name: 3kw 24v Hybrid Inverter IP54
Brand: Devsol
SKU: 34
Price: 50426.00 INR
Availability: InStock

3kw 24v Hybrid Inverter IP54 - Overview

DEV HYD 3KW 24V
Smart. Powerful. Reliable.
Features
3000W Rated Power
24V Battery System
Pure Sine Wave Output
MPPT Solar Charger
500VDC Max PV Input
Intelligent LCD Display
BMS Communication Support
Wi-Fi Monitoring Support
Multiple Protection System
230VAC Output Voltage
50Hz Output Frequency
Suitable for Home / Shop / Office
IP54 Protection
5 Year Warranty
Specifications
Parameter
Specification
Product Name
Hybrid Solar Inverter
Brand
DEVSOL
Model
DEV HYD 3KW 24V
Rated Power
3000W
Battery Voltage
24VDC
Output Voltage
230VAC
Output Frequency
50Hz
Output Waveform
Pure Sine Wave
Solar Charger Type
MPPT
Max PV Input Voltage
500VDC
Display
Intelligent LCD
Communication
BMS + Wi-Fi
Protection Grade
IP54
Application
Home / Shop / Office
Warranty
5 Years
Footer Highlights
Smart Technology
High Efficiency
Clean Energy
Safe & Reliable
Maximum Performance

Key Features

Transformer-less design on 9G/9G Pro models
IP54, IP65 or IP66 protection depending on model
Battery-optional operation
Single and three-phase parallel options
MPPT charge controller with 100A and 160A variants
Generator synchronization
Touch-screen or large LCD display on supported models
Remote monitoring or inbuilt Wi-Fi on supported models
Supports lead-acid, tubular, lithium and sodium batteries

Why Choose Devsol Hybrid 9G Inverter?

Devsol hybrid inverters are made in India and India-repairable. The 9G and 9G Pro range includes transformer-less models with IP54, IP65 and IP66 protection depending on SKU, including IP66 on the 6kW 48V 9G model and IP54 on the 5kW 24V model. They can run battery-less in on-grid style, with a battery addable later. Parallel models (6/8/10/12kW) configure as single or three phase, with generator sync and remote operation.

Learn more: Best Hybrid Solar Inverter in India

Frequently Asked Questions

Q. Can the Devsol hybrid inverter run without a battery?

A. Yes. Devsol hybrid inverters can run battery-less in an on-grid style and a battery can be added later.

Q. Which IP ratings are available in Devsol hybrid inverters?

A. Devsol product records show IP54, IP65 and IP66 protection depending on the model, including IP66 on the 6kW 48V 9G model and IP54 on the 5kW 24V model.

Q. Does it support single and three phase?

A. Yes, parallel models such as 6kW, 8kW, 10kW and 12kW can be configured single or three phase and support generator sync.

Q. Is it repairable in India?

A. Yes. Devsol inverters are made in India and India-repairable.

3kw 24v Hybrid Inverter IP54

₹50,426
